| 123 |
4*USB 2.0
1*Giga LAN
Max1920*1280
PHOENIX BUS terminal
0-10V
Linear type, Disk type, Servo type
Auto and Manual measurement
Fixed tool calibration, Mobile tool calibration, First calibration & Calibration after tool change
Workpiece compensation, Screw error compensation, Backlash compensation, AQE compensation, Tool compensation
*.G；*.NC；*.UG;*.DEMO;*.ISO;*.ENG;*.CUT;*.DXF;*.PLT;*.TXT
Supporting G54~G59 and WCS origin saving
Multi-tasking, Array function, Mirror & Rotate, Multi-layer machining, Cycle machining
Handwheel guide, Breakpoint resume, Tool selection
S-type, LEP, Acceleration T type algorithms
Chinese, English
Alarms of program error, operation error, over-travel error, PLC error and IO communication error
